- Engine model
- OC60-E4
- Emission regulation
- EPA/CARB Tier 4 (NRTC/NTE test mode) + EU Stage V
- Type
- Vertical, liquid-cooled 4-cycle diesel engine
- Cylinders
- 1
- Bore and stroke
- mm (in)
- 72.0 x 68.0 (2.83 x 2.68)
- Displacement
- L (cu.in)
- 0.276 (16.8)
- Maximum output / speed*1
- kW (HP) / rpm
- 4.5 (6.0) / 3600
- Continuous output / speed*1
- kW (HP) / rpm
- 4.1 (5.5) / 3600
- Maximum torque / speed
- Nm (lb-ft) / rpm
- 13.2 (9.7) / 2000 to 2600
- Combustion system
- Indirect Injection
- Fuel tank capacity
- L (U.S. gal)
- 3.5 (0.92)
- Lubricating oil capacity
- L (U.S. gal)
- 1.3 (0.34)
- Starter capacity
- V - kW
- 12 - 0.7
- Charging dynamo
- V - W
- 12 - 48 (L1 model: 12 - 170)
- Length x Width x Height
- mm (in)
- 403 x 461 x 458 (15.9 x 18.1 x 18.0)
- Dry weight*2
- kg (lb)
- 38 (84)
