- Engine model
- D1803-CR-E4B
- Emission regulation
- EPA/CARB Tier 4 + EU Stage IIIA
- Type
- Vertical, water cooled 4-cycle diesel engine
- Cylinders
- 3
- Bore and stroke
- mm (in)
- 87.0 x 102.4 (3.43 x 4.031)
- Displacement
- L (cu.in)
- 1.826 (111.4)
- Aspiration
- Naturally aspirated
- Aftertreatment
- DOC + DPF
- Rated output / speed*1
- kW (HP) / rpm
- 28.0 (37.5) / 2700
- Maximum torque / speed*1
- Nm (lb-ft) / rpm
- 115.8 (85.4) / 1600
- Combustion system
- Direct injection
- Fuel system
- Common rail system
- Length x Width x Height*2
(without aftertreatment unit) - mm (in)
- 551 x 536 x 711 (21.7 x 21.1 x 28.0)
- Length x Width x Height*3
(with aftertreatment unit) - mm (in)
- 746 x 536 x 721 (29.4 x 21.1 x 28.4)
- Dry weight
- kg (lb)
- 185 (407)
