- Engine model
- EA330-E4
- Emission regulation
- EPA/CARB Tier 4 (NRTC/NTE test mode) + EU Stage V
- Type
- Vertical, water cooled 4-cycle diesel engine
- Cylinders
- 1
- Bore and stroke
- mm (in)
- 77.0 x 70.0 (3.03 x 2.76)
- Displacement
- L (cu.in)
- 0.325 (19.8)
- Maximum output / speed*1
- kW (HP) / rpm
- 5.15 (6.91) / 3000
- Continuous output / speed*1
- kW (HP) / rpm
- 4.4 (5.9) / 3000
- Maximum torque / speed
- Nm (lb-ft) / rpm
- 17.65 (13.02) / 2000
- Combustion system
- Indirect Injection
- Fuel tank capacity
- L (U.S. gal)
- 4.8 (1.3)
- Lubricating oil capacity
- L (U.S. gal)
- 1.3 (0.34)
- Starter capacity
- V - kW
- 12 - 1.1
- Charging dynamo
- V - W
- 12 - 60
- Length x Width x Height
- mm (in)
- 312 x 566 x 457 (12.3 x 22.3 x 18.0)
- Dry weight*2
- kg (lb)
- 54 (120)
