- Engine model
- V3600-T-E3B
- Emission regulation
- EPA/CARB Tier 3 + EU Stage IIIA
- Type
- Vertical, water cooled 4-cycle diesel engine
- Cylinders
- 4
- Bore and stroke
- mm (in)
- 98.0 x 120.0 (3.86 x 4.724)
- Displacement
- L (cu.in)
- 3.620 (220.9)
- Aspiration
- Turbocharged
- Aftertreatment
- -
- Rated output / speed*1
- kW (HP) / rpm
- 63.0 (84.5) / 2600
- Maximum torque / speed*1
- Nm (lb-ft) / rpm
- 296.0 (218.0) / 1600
- Combustion system
- Indirect injection
- Fuel system
- In-line pump
- Length x Width x Height*2
(without aftertreatment unit) - mm (in)
- 699 x 537 x 794 (27.5 x 21.1 x 31.3)
- Length x Width x Height*3
(with aftertreatment unit) - mm (in)
- -
- Dry weight
- kg (lb)
- 261 (575)
